ggsql continues to evolve and today we are pleased to announce the release of ggsql 0.4.0. This release is heavy on features and we hope this blog post can get you excited about where we are taking the project.

There are two headline features for 0.4.0: Spatial plotting and within-layer aggregation of data. Apart from these two there is a grab back of smaller improvements we will list in the end.

Spatial support#

For the spatial features we leverage the ability of databases to work with spatial data continuing our ethos of pushing compuations to the backend. Not every database supports the spatial abilities that we need for plotting, but we have tested the DuckDB spatial extension, PostGIS, and SpatiaLite.

World dataset#

The spatial feature comes with a new built-in dataset to offer useful examples. This new dataset ggsql:world comes from the Natural Earth project, and contains country shapes at 110m resolution. We’ve included a subset of columns, including country names and ISO Alpha-3 codes for identification, continent and subregion for grouping or discrete variables, income group as an ordinal variable, and population/GDP as continuous variables. The geom column in the dataset contains the country border data in a binary format called Well-Known Binary (WKB) which will be decoded by ggsql into the actual coordinates. In general, as long as the data in the geometry column can be converted to WKB by the backend it can be used.

Spatial layer#

To visualise spatial features we have made a new spatial layer. Instead of taking classical x/y position aesthetics, it uses a geometry aesthetic to which the WKB features should be mapped. There are some heuristics in place that try to detect this column in the data, but should that fail you can fall back to MAPPING {column_name} AS geometry. Other than that, it is a layer acting much like polygons.

VISUALISE continent AS fill FROM ggsql:world
  DRAW spatial

Turning spatial layers in to a choropleth map is as easy as mapping a continuous variable to the fill aesthetic. Per usual, the scale system allows control over how the fill aesthetic is mapped.

VISUALISE gdp AS fill FROM ggsql:world
  DRAW spatial
  SCALE fill TO magma VIA log10

Map projections#

In addition to the spatial layer we also added new options to the PROJECT clause to support map projections. In this release we provide reasonable support for 21 map projections, which are accessible by name. For example, the orthographic projection shows Earth as it would appear from a great distance in space with a hemisphere facing the viewer.

VISUALISE FROM ggsql:world
  DRAW spatial
  PROJECT TO orthographic

One might notice that the light gray that denotes panel area has shrunk to a circle, displaying visible area where one might expect map data to occur. This background display in combination with strategic slicing of geometry (try PROJECT TO igh to see what we mean) is what we count as ‘supported’. We allow custom projections using PROJECT TO crs SETTING target => {proj string}. Even when using PROJECT TO crs we attempt to detect any supported projections from the proj string and provide the additional support. The downside of unsupported projections is that we have not considered what the visible area looks like, so instead one can expect a generic gray panel area. Moreover, we also don’t do strategic slicing which causes geometry outside the bounds of the projection to become invalid and excluded. For example, in the projection below we ought to have parts of North America, Russia, India and Antarctica in view but these get dropped. The best advise in such cases is to prepare the data yourself before plotting it.

VISUALISE FROM ggsql:world
  DRAW spatial
  PROJECT TO crs SETTING target => '+proj=adams_hemi'

Depending on the projection, we also support origin and parallel parameters that give convenient access to the +lon_0, +lat_0, +lat_1, +lat_2 proj string parameters. The origin is widely applicable across projections, whereas parallel is more of a specialty parameter for e.g. the albers equal area projection. In addition the bounds argument can constrain the view to focus on a particular area and clip away other geometry. Here, we use bounds to trim the view to the Northern Americas.

VISUALISE FROM ggsql:world
  DRAW spatial
  PROJECT TO albers SETTING
    origin => (-96, 40),
    parallel => (40, 60),
    bounds => (-3765000, -1532628, 3074952, 5509261)

You can also display a limited set of other layers using map projections. For ‘crimes against datavis’-reasons, we don’t support boxplots, density plots or histogram layers. We do support several graphical primitives like path, polygon, rect, text and point. For line segments we assume that they are straight in whatever origin coordinate system they are, add additional vertices and then project them to the target system. This causes them to curve along with projections.

VISUALISE
  DRAW spatial MAPPING FROM ggsql:world
  PLACE path
    SETTING lon => (-70.7, -109.3), lat => (-33.4, -27.1), stroke => 'red'
  PLACE text
    SETTING lon => -109.3, lat => -27.1, label => 'Rapa Nui'
  PROJECT TO orthographic
    SETTING origin => (-90, -20)

Note that we’re using lon and lat as position aesthetics here because we work with map projections. You can use x and y as position aesthetics, but you’d have to instruct PROJECT x, y TO ... to use that interpretation. The following code block is equivalent to the one above.

VISUALISE
  DRAW spatial MAPPING FROM ggsql:world
  PLACE path
    SETTING x => (-70.7, -109.3), y => (-33.4, -27.1), stroke => 'red'
  PLACE text
    SETTING x => -109.3, y => -27.1, label => 'Rapa Nui'
  PROJECT x, y TO orthographic
    SETTING origin => (-90, -20)

Future spatial plans#

If you want to use your own country-level data with the world dataset, you can use a left-join. This has the drawbacks that you have to do the join yourself, the country identifiers must match exactly, and that the detail level must be sufficient. We hope we can make this more ergonomic in the future, and we’ll be looking into scales for the geometry aesthetic that can take away some of the hassle.

WITH data(country, tfr) AS (VALUES
  ('Japan', 1.1),
  ('South Korea', 0.7),
  ('China', 1.0),
  ('Vietnam', 1.9),
  ('Thailand', 1.2),
  ('Philippines', 1.9)
),
world AS (SELECT * FROM ggsql:world)
SELECT * FROM data LEFT JOIN world ON country = name
VISUALISE tfr AS fill
  DRAW spatial
  PROJECT TO lambert SETTING origin => (110, 10)

In addition, we want to look into several PLACE layers to quickly jot down some spatial context, like PLACE borders, PLACE water or things of the sort.

Aggregation#

Aggregation support is a major step towards providing a grammar of graphic API that is flexible within the bounds of the SQL syntax. If you have experience with ggplot2 you may be used to using stat_summary() together with different geoms to render summary statistics with various graphical representations. In ggsql we don’t have the ability to mix and match geoms and stats (by design, the dichotomy is a common source of user confusion in ggplot2) so something else has to come instead: Enter aggregations…

In ggsql all layers that draw their data directly (i.e. doesn’t have any statistical transformation involved) now accepts an aggregate setting. Below we will explore what this provides.

At it’s basic the aggregate setting names an aggregation function to apply to all numeric aesthetics within a group to reduce it to a single row. As an example that is both simple and immediately useful let’s consider the following plot:

VISUALIZE bill_len AS x, bill_dep AS y FROM ggsql:penguins
DRAW point
  MAPPING species AS fill
DRAW text
  MAPPING species AS label
  SETTING
    aggregate => 'mean',
    stroke => 'white',
    fontsize => 18,
    fontweight => 'bold'

Both the point layer and the text layer access the full dataset, but while the point layer draws each individual point, the text layer aggregates all the row that shares discrete mapping (the label mapping in this case). All numeric mappings (x and y) are aggregated using the aggregate function (mean) resulting in three labels, each placed at the geometric mean of their respective point cloud.

If you do not want to use the same aggregation function for all numeric mapping you can explicitly target them (here using the 75 percentile for y):

VISUALIZE bill_len AS x, bill_dep AS y FROM ggsql:penguins
DRAW point
  MAPPING species AS fill
DRAW text
  MAPPING species AS label
  SETTING
    aggregate => ('x:mean', 'y:p75'),
    stroke => 'white',
    fontsize => 18,
    fontweight => 'bold'

Some layers are range based by nature, such as the ribbon and range layer. For these you can provide two untargeted aggregation functions:

VISUALIZE Day AS x, Temp AS ymin, Temp AS ymax FROM ggsql:airquality
DRAW ribbon
  SETTING aggregate => ('min', 'max')

This is especially useful for on-the-fly error bars etc.

VISUALIZE species AS x, body_mass AS y FROM ggsql:penguins
DRAW bar
  SETTING aggregate => ('mean')
DRAW range
  MAPPING body_mass AS ymin, body_mass AS ymax
  SETTING aggregate => ('mean-1.5sdev', 'mean+1.5sdev')

If you provide multiple targeted aggregation functions to the same mapping each group collapses to multiple rows and you get an aggregate column naming the aggregate function you can map to.

VISUALIZE species AS y FROM ggsql:penguins
DRAW range
  MAPPING body_mass AS xmin, body_mass AS xmax
  SETTING aggregate => ('min', 'max'), hinge => null
DRAW point
  MAPPING body_mass AS x
  REMAPPING aggregate AS fill
  SETTING aggregate => ('x:min', 'x:max'), opacity => 1, size => 10

We believe this new feature will allow much richer operations directly within ggsql alleviating the need to precalculate summary statistics before plotting etc. As a last example of the power this provides let’s create a candlestick chart showing temperature per week:

VISUALISE Date AS x, Temp AS ymin, Temp AS ymax, Temp AS color
  FROM ggsql:airquality
DRAW range
  REMAPPING aggregate AS linewidth
  SETTING
    aggregate => (
      'x:first',
      'ymin:first', 'ymin:min',
      'ymax:last', 'ymax:max',
      'color:diff'
    ),
    hinge => null
  PARTITION BY Week
SCALE linewidth TO (5, 1)
SCALE BINNED color TO ('steelblue', 'firebrick')
  SETTING breaks => (-20, 0, 20)

You can read more about aggregate in the documentation.

Other additions#

Those were the main attractions, but we have more to show still. Below is a quick glance at some of the other new features. See the changelog for a full overview along with bugfixes etc.

ADBC reader#

The reception to our alpha release was amazing and users have been quick to request support for their backend of choice. We can’t wait to support as many databases as possible but we have held off for a bit on most to get other infrastructure in place. One exception is a general ADBC reader since it opens the door for a huge swath of backends right out of the gate. Together with the ODBC reader there should now be rudimentary support for a great deal of databases as many provides drivers for either ODBC or ADBC.

Polar improvements#

We have made improvements to the polar projection in a few different ways.

  • We now render proper axes, grid lines, and background for polar projections in the Vega-Lite writer. Vega-Lite itself doesn’t have a concept of a polar coordinate system so we had to handroll all of these.
  • You can now make radar plots by scaling the angle aesthetic with a discrete scale.

An example of both can be seen below:

WITH data(angle, radius) AS (VALUES
  ('A', 5),
  ('B', 2),
  ('C', 4),
  ('D', 7),
  ('E', 6)
)
VISUALIZE angle, radius FROM data
DRAW polygon

Half-side variants#

Both violin, boxplot, and jittered points can now be displayed in a half variant. This opens up for the creation of ridge plots by rendering only the top half of vertical violins:

VISUALIZE Species AS y, body_mass AS x FROM ggsql:penguins
DRAW violin
  SETTING side => 'top', width => 3

Another option is to combine two different layers into a single representation showing e.g. both sumary statistics and the raw data:

VISUALIZE Species AS x, body_mass AS y FROM ggsql:penguins
DRAW point
  SETTING position => 'jitter', side => 'right'
DRAW boxplot
  SETTING side => 'left', hinge => 5, outliers => false
